306200-22941 Opalume Catenary

Light distribution

Direct

Diffuser

Opal

No. of LEDs

21

Lens

E1

Colour

Grey

Lumen output

17866

CLO function active

Yes

CLO time, h

100000

lm/W

144

Light source colour

740

CCT, K

4000

CRI

70

SDCM

5

Lumen maintenance 100 000 h

L100

LED driver, h/max failure %

100000/10

LED driver, 2 h/max failure %

100000/10

Energy class, LED module

D

Driver brand

Philips

Power on last level

Yes

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

50, 60

Protective class

1

IP rating

66

IK rating

08

Start W

123

End W

135

Average W

129

Stand by W

0.5

Min. ambient temperature, °C

-40

Max. ambient temperature, °C

25

MCB B10A, pcs

2

MCB B16A

4

MCB C10A

4

MCB C16A

7

Surge protection CM, kV/kA

10

Surge protection DM, kV/kA

6

Power factor, 100 %

0.97

Projected wind area, m2

0.140

NTC function

Yes

Height, mm

375

Diamater, mm

507

Weight, kg

14.9
