Pleiad G4 Robust

Downlight with protection class IK 10 for increased security. The reflector ring is fastened with a safety screw to prevent access and dismantling.

Installation

Recessed mounting in unventilated or ventilated suspended ceilings. Separate driver and installation clip for easy and tool-free installation supplied as standard. An assembly plate must be used when mounting on soft tile ceilings, see accessories. For detailed information, see the installation instructions.

Connection

Connection in separate driver box. Snap-in terminal block 3x1.5 mmm² (x2), onward connection possible. 5x1.5 mm² (x2) when dimming. Can also be supplied with chassis mounted snap-in connector in the ballast where a T-splitter or mains cable and plug are possible. The luminaire body and driver are interconnected with a snap-in connector.

Design

Luminaire body in cast aluminium. Two-part visible edge ring in aluminium. The luminaire has durable PETG plates in the light openings between the rings. The luminaire and the edge rings are locked using tamper-proof torx screws.

Reflector

Reflector of metallised aluminium. Lens of clear acrylic.

Miscellaneous

IK 10. IP 64 under a suspended ceiling, IP 20 above a suspended ceiling. Luminaire body Class III. The supplied driver must be connected to the protective earth. Luminaires with Tunable White (2700 – 6500 K) are equipped with driver DALI Device type 8. For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation. CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Pleiad G4 – Installation

Pleiad G4

Pleiad G4 is the latest generation of Fagerhult’s classic Pleiad downlight series. Even more efficient. Even better visual comfort. Even quicker to install.

Pleiad G4 simplifies and streamlines advanced lighting planning for...

More about the family Pleiad G4

Document

Customise with Fagerhult Configure

Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.

  • Adapt and optimise the luminaire
  • Download unique data sheet and light data files
  • To order, contact your sales representative
Start configuration

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Wieland T-connector Wieland 5-way T-connector 91026
Wieland T-connector Wieland 3-way T-connector 91025
Mounting plate Mounting plate 41956
WAGO connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 91244
WAGO connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 91243
Wieland connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92793
WAGO T-connector WAGO T-Connector, 3-way, white 91067
WAGO T-connector WAGO T-connector, 5-way, 2 locking levers, blue 88228
Wieland connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92799
Cover plate IP 21 Cover plate IP 21, Ø165 41060
Retrofit kit Retrofit kit Ø 205-310 mm 41087
no-image placeholder Ensto connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92786
no-image placeholder Ensto connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92785
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free. 92788
Ensto T-connector Ensto T-connector 3-way, white 92783
Ensto T-connector Ensto T-connector 5-way, grey 92784
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free. 92787
