Pleiad G4 165

Efficient downlight with excellent technical lighting properties. Choose between several luminous fluxes, reflector options and distribution angles. Also available with Tunable White, RGB/W and integrated emergency lighting.

Installation

Recessed mounting in unventilated or ventilated suspended ceilings. Separate driver and installation clip for easy and tool-free installation supplied as standard. An assembly plate must be used when mounting on soft tile ceilings, see accessories. For detailed information, see the installation instructions.

Connection

Connection in separate driver box. Snap-in terminal block 3x1.5 mmm² (x2), onward connection possible. 5x1.5 mm² (x2) when dimming. Can also be supplied with chassis mounted snap-in connector in the driver where a T-splitter or mains cable and plug are possible. The luminaire body and driver are interconnected with a snap-in connector.

Design

Luminaire body in cast aluminium. Visible reflector ring in white aluminium (RAL 9003).

Reflector

Reflector of matt metallised aluminium, white (RAL 9003) or black (RAL 9005) finish. Reflector ring in white aluminium (RAL 9003). Lens of clear acrylic.

Miscellaneous

The luminaire is supplied with dust protection over the light opening. IP 64 under a suspended ceiling, IP 20 above a suspended ceiling. Luminaire body Class III. The supplied driver must be connected to the protective earth. Luminaires with Tunable White (2700 – 6500 K) are equipped with driver DALI Device type 8. Luminaires with RGB/W are equipped with driver DALI Device type 6 (4 addresses / luminaire). Also available for DMX on request.
For loads in the suspended ceiling system, follow the selected suspended ceiling supplier’s recommendation. CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Media

Pleiad G4 – Installation

Pleiad G4

Pleiad G4 is the latest generation of Fagerhult’s classic Pleiad downlight series. Even more efficient. Even better visual comfort. Even quicker to install.

Pleiad G4 simplifies and streamlines advanced lighting planning for...

More about the family Pleiad G4

Document

Customise with Fagerhult Configure

Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.

  • Adapt and optimise the luminaire
  • Download unique data sheet and light data files
  • To order, contact your sales representative
Start configuration

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Wieland T-connector Wieland 5-way T-connector 91026
Ice Ø 165 41315
Wieland T-connector Wieland 3-way T-connector 91025
Recess panel Ø 165 mm 41775
Mounting plate Mounting plate 41956
Retrofit kit Retrofit kit Ø 165–270 mm 41339
Input unit, Tridonic DALI XC 86132
Sloping ceiling cylinder Sloping ceiling cylinder, Ø 165 41638
Mounting plate Mounting plate 625 with deflector. Adapted for downlights with recess dimensions Ø 165 41933
Mounting plate Mounting plate 600 with deflector. Adapted for downlights with recess dimensions Ø 165 41932
Mounting plate Mounting plate HB. Adapted for downlights with recess dimensions Ø 165. For 38 mm support rail. 41655
Cover plate clear IP 64 Ø 165 mm, matt aluminium 41848
Cover plate clear IP 64 Ø 165 mm, grey (RAL 7040) 41844
Cover plate clear IP 64 Ø 165 mm, white (RAL 9016) 41840
Cover plate opal IP 54 Ø 165 mm, grey (RAL 7040) 41864
Mounting plate and support bars 625 mm 41959
Cover plate opal IP 54 Ø 165 mm, white (RAL 9016) 41860
Mounting plate and support bars 600 mm 41958
Cover plate Delta IP 20 Ø 165 mm, white (RAL 9016) 42031
Cover plate Delta IP 20 Ø 165 mm, matt aluminium 42039
Cover plate Delta IP 20 Ø 165 mm, grey (RAL 7040) 42035
Cover plate opal IP 54 Ø 165 mm, matt aluminium 41868
Edge ring II Ø 165 mm, white (RAL 9016), height 11 mm, external diameter 199 mm. 41900
Ringlight Ø 165 mm, white (RAL 9016) 41750
Edge ring II Ø 165 mm, grey (RAL 7040), height 11 mm, external diameter 199 mm. 41904
Ringlight Ø 165 mm, blasted glass 41754
Edge ring II Ø 165 mm, matt aluminium, height 12 mm, external diameter 200 mm. 41908
Control panels, Lunatone DALI Switch Cross 86354
Edge ring III Ø 165 mm, matt aluminium, height 10 mm, external diameter 196 mm. 41928
Edge ring III Ø 165 mm, white (RAL 9016), height 9 mm, external diameter 195 mm. 41920
Edge ring III Ø 165 mm, grey (RAL 7040), height 9 mm, external diameter 195 mm. 41924
WAGO connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 91244
WAGO connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 91243
Wieland connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92793
WAGO T-connector WAGO T-Connector, 3-way, white 91067
WAGO T-connector WAGO T-connector, 5-way, 2 locking levers, blue 88228
Wieland connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92799
Cover plate IP 21 Cover plate IP 21, Ø165 41060
Cover plate clear IP 64 Ø 165 mm, white (RAL 9016) Margard hard coated 41708
Cover plate opal IP 54 Ø 165 mm, black (RAL 9005 G10) 41157
Cover plate Delta IP 20 Ø 165 mm, black (RAL 9005 G10) 41154
Cover plate clear IP 64 Ø 165 mm, black (RAL 9005 G10) 41160
Edge ring III Ø 165 mm, black (RAL 9005 G10), height 9 mm, external diameter 195 mm. 41142
Edge ring II Ø 165 mm, black (RAL 9005 G10), height 11 mm, external diameter 199 mm. 41139
no-image placeholder Ensto connection cables, 5-way Length 3.0 m with female and male connectors, 5x1,5 mm². Halogen free. 92786
no-image placeholder Ensto connection cables, 3-way Length 3.0 m with female and male connectors, 3x1,5 mm². Halogen free. 92785
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 5x1,5 mm². Halogen free. 92788
Ensto T-connector Ensto T-connector 3-way, white 92783
Ensto T-connector Ensto T-connector 5-way, grey 92784
no-image placeholder Ensto power cable Length 2.0 m with female (without hooks) and male connectors, 3x1,5 mm². Halogen free. 92787
