Vialume 1 Crossing

A post top luminaire with lenses specially developed for crossings (right-hand traffic). CLO for output consistency as standard.

Installation

Post top luminaire which in its standard design is mounted on a Ø 48 mm post arm bracket. 60 mm post top bracket supplied with luminaire. For other mounting types and other options, see Accessories which are ordered separately. Variable tilting function ± 15º for perfect installation. Post height 5–8 m.

Connection

Connection cable 10 m 3x1,5 mm² type H07RN-F. DALI version available on request, delivered with a 5-pin cable. Other cable versions on request.

Design

Body and post bracket in cast aluminium. Aluminium-zinc coated stainless screws. Driver is integrated in the luminaire. Hardened flat glass IK09. PMMA diffuser with IK10 on request.

Optics

The lenses are specially developed for crossings (right-hand traffic).

Dimming

DALI version is available on request.

Designed by

ÅF Lighting and Tuxen Design.

Standard colour

Alu-grey (RAL 9006, semi-gloss).
Anthracite grey (Gris 900 Sablé), black (RAL 9005) or white (RAL 9010, semi-gloss) on request.

LED-information

DALI version is equipped with NTC, over-heat protection.
Driver with integrated surge protection (6 kV).
Extra surge protection (10 kV) available on request.

Miscellaneous

Available in Classes 1 and 2.
Luminaire with Zhaga D4i-certified driver on request. NEMA socket on request.

CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.

Vialume

Vialume – Fagerhult’s first self-manufactured post top luminaire for roads and city streets – is taking inspiration from the beautiful Nordic light. The luminaire is characterised by a soft, organic shape with simple lines, which ...

More about the family Vialume

Document

Specification

Loading...

Filter

Name Description Art.no.
Name Description Art.no.
Bracket for Vialume 1 Bracket for Ø 76 mm post top. Alu-grey. 309902
Bracket for Vialume 1 Bracket for Ø 60 mm post top. Alu-grey. 309901
Double post-top bracket for Vialume 1 Double post-top bracket for Ø 76 mm post top. Alu-grey. 309904
Double post-top bracket for Vialume 1 Double post-top bracket for Ø 60 mm post top. Alu-grey. 309903
no-image placeholder Spigot for post arm Ø 60 mm Anthracite grey (Gris 900 Sablé). 301050-329
no-image placeholder Spigot for post arm Ø 60 mm Alu-grey (RAL 9006, gloss 70). 301050-235
no-image placeholder Spigot for post arm Ø 60 mm Black (RAL 9005) 301050-230
no-image placeholder Spigot for post arm Ø 60 mm White (RAL 9010, gloss 50) 301050-311
Spigot for post arm Ø 60 mm Untreated 301050
Wall bracket for Vialume and Opalume Wall bracket arm Ø 48 (standard). 303677-235
